ACIG Database
Vietnam War
 |
| This and the following two pictures show the characteristing North Vietnamese SA-2 sites, all with their "star"-pattern. |
 |
| At least as interesting were North Vietnamese AAA-sites, like this one, with 57mm AAA guns. |
Egypt, 1970-1973
 |
| Egyptian SA-2 site in Sinai, photographed by IDF/AF F-4Es during an attack. |
 |
| The same site several moments later, while being hit by several Mk.82s. |
 |
| This is an Egyptian decoy SA-2 site, captured by the Israelis in 1973 north of the Suez City. |
Syria, 1982
 |
| Sadly, no photos of whole Syrian SAM-sites are available yet: this photograph shows only a part of a Syrian SA-6 site built near the Beirut-Damascus highway, and overlooking the Bekaa Valley, in early 1982. |
I Persian Gulf War, 1980-1988
 |
| An Iraqi SA-2 site, as seen from the RF-4E at which it was firing, in 1982. |
 |
| This is an Iraqi SA-3 site, again photographed by Iranian RF-4E (note the shade of the Phantom in the lower right corner). |
 |
| This is also an Iraqi SA-3 site, but this time some 40km SW from Basrah (actually, this was one of the sites defending as-Shoibiyah AB from the south), photographed by high-flying RF-4E in 1986. |
 |
| There are - sadly - not many known photographs showing western-type of SAM-sites. This one is the Iranian MIM-23B site on the small Khark Island, photographed in 1986 (note the orange circle); sadly, not many details can be seen. |
II Persian Gulf War, 1991
 |
| A better view of a Fansong radar as seen during a display in Iraq, in 1989 or 1990. |
 |
| An Iraqi Flat Face radar as seen during defence exhibition in 1989. |
 |
| Iraqi Fansong radar, captured by US troops in 1991... |
 |
| On the same site also this SA-2 was captured... |
 |
| ...and another one, still on its transport trailer. |
Bosnia, 1995 & Kosovo, 1999
 |
| P-35 radar of the former Yugoslav Air Force and Air Defence Force (JRViPVO), seen in a typical position atop a hill. |
 |
| S-75MK Fansong radar as seen in service with the former JRViPVO. |
 |
| An interesting series of photographs showing the re-loading process of a SA-2 Guideline SAM... |
 |
| Some Bosnian Serb SA-2 equipment, photographed in mid-1990s at one of several UN-collection points. |
